INDM
Input from I/O and Decrement
Operation
(HL) ← ({UU, 00h, C})
B ← B – 1
C ← C – 1
HL ← HL – 1
Description
The CPU places the contents of register C onto the lower byte of the address bus,
ADDR[7:0]. The upper byte of the address bus, ADDR[23:16] is undefined for I/O
addresses. The CPU reads the byte located at this I/O address into CPU memory. The CPU
next places the contents of HL onto the address bus and writes the byte to the memory
address specified by the HL register. Next, the CPU decrements the B, C, and HL regis-
ters, and sets the Z Flag to 1 if the B register is decremented to 0.
Condition Bits Affected
Attributes
S Undefined.
Z Set if B – 1 = 0; reset otherwise.
H Undefined.
P/V Undefined.
N Set if msb of data is a logical 1; reset otherwise.
C Undefined.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
INDM —X 5ED, 8A
INDM.S —1 652, ED, 8A
INDM.L —0 649, ED, 8A
