ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
169
INDR
Input from I/O and Decrement with Repeat
Operation
repeat {
(HL) ← ({UU, BC[15:0]})
B ← B – 1
HL ← HL – 1
} while B ≠ 0
Description
The CPU places the contents of BC[15:0] onto the lower two bytes of the address bus,
ADDR[15:0]. The upper byte of the address bus, ADDR[23:16] is undefined for I/O
addresses. The CPU reads the byte located at I/O address {UU, BC[15:0]} into CPU mem-
ory. The CPU next places the contents of HL onto the address bus and writes the byte to
the memory address specified by the HL register. Next, the CPU decrements the B and HL
registers, and sets the Z Flag to 1 if the B register is decremented to 0. The instruction
repeats until the B register equals 0.
Condition Bits Affected
Attributes
S Not affected.
Z Set of B – 1 = 0; reset otherwise.
H Not affected.
P/V Not affected.
N Set if msb of data is a logical 1; reset otherwise.
C Not affected.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
INDR —X 2 + 3 * BED, BA
INDR.S —1 3 + 3 * B52, ED, BA
INDR.L —0 3 + 3 * B49, ED, BA
