ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
172
INI2
Input from I/O and Increment
Operation
(HL) ← ({UU, BC[15:0})
B ← B – 1
C ← C+1
HL ← HL+1
Description
The CPU places the contents of BC[15:0] onto the lower two bytes of the address bus,
ADDR[15:0]. The upper byte of the address bus, ADDR[23:16] is undefined for I/O
addresses. The CPU reads the byte located at this I/O address into CPU memory. The CPU
next places the contents of HL onto the address bus and writes the byte to the memory
address specified by the HL register. The B register decrements. The C and HL registers
increment. Next, the CPU sets the Z Flag to 1 if the B register decrements to 0.
Condition Bits Affected
Attributes
S Not affected.
Z Set if B – 1 = 0; reset otherwise.
H Not affected.
P/V Not affected.
N Set if msb of data is a logical 1; reset otherwise.
C Not affected.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
INI2 ——5ED, 84
INI2.S ——652, ED, 84
INI2.L ——649, ED, 84
