JR d
Jump Relative
Operation
PC ← PC+d
Description
The two’s-complement displacement d is added to the Program Counter. The jump is mea-
sured from the address of the byte following the instruction.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
JR d X318, dd
