eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
197
LD (HL), n
Load Indirect
Operation
(HL)
←
n
Description
The 8-bit immediate
n
operand is written to
the memory location specified by the contents
of the multibyte CPU
register HL.
Condition Bits Affected
None.
Attributes
Mnemonic
Operand
ADL Mode
Cycle
Opcode (hex)
LD
(HL),
n
X3
36, nn
LD.S
(HL),
n
14
52, 36, nn
LD.L
(HL),
n
04
49, 36, nn
