UM007714-0908 CPU Instruction Set
256
OTD2R
Output to I/O and Decrement with Repeat
Operation
repeat {
({UU, DE[15:0]}) ← (HL)
BC ← BC – 1
DE ← DE – 1
HL ← HL – 1
} while BC ≠ 0
Description
The CPU loads the contents of the memory location specified by the multibyte HL register
into CPU memory. This byte is output to I/O address {UU, DE[15:0]}. The upper byte of
the address bus, ADDR[23:16] is undefined for I/O addresses. The BC, DE, and HL regis-
ters are decremented. The instruction repeats until the BC register equals 0.
Condition Bits Affected
Attributes
Note
This instruction operates differently in eZ80190 device. In the eZ80190, operation is:
repeat {
({UU, BC[15:0]}) ← (HL)
B ← B – 1
S Not affected.
Z Set if B C– 1 = 0; reset otherwise.
H Not affected.
P/V Not affected.
N Set if msb of data is logical 1; reset otherwise.
C Not affected.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
OTD2R —X 2 + 3 * BED, BC
OTD2R.S —1 3 + 3 * B52, ED, BC
OTD2R.L —0 3 + 3 * B49, ED, BC
