ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
284
PUSH IX/Y
Push Stack
Operation
if ADL mode {
(SPL – 1) ← IX/Y[23:16]
(SPL – 2) ← IX/Y[15:8]
(SPL – 3) ← IX/Y[7:0]
SPL ← SPL – 3
}
else Z80 mode {
(SPS – 1) ← IX/Y[15:8]
(SPS – 2) ← IX/Y[7:0]
SPS ← SPS – 2
}
Description
In ADL mode, or when the .L suffix is employed, 3 bytes are pushed onto the memory
locations indicated by SPL, in the following sequence:
1. The CPU writes the contents of the upper byte of the specified Index Register, IXU or
IYU, to the memory location with address SPL
– 1.
2. The CPU next writes the contents of the High byte of the specified Index Register,
IXH or IYH, to the memory location with address SPL
– 2.
3. The CPU next writes the contents of the Low byte of the specified Index Register, IXL
or IYL, to the memory location with address SPL
– 3.
SPL decrements by three.
In Z80 mode, or when the
.S suffix is employed, 2 bytes are pushed onto the memory loca-
tions indicated by SPS, in the following sequence:
1. The CPU writes the contents of the High byte of the specified Index Register, IXH or
IYH, to the memory location with address SPS
– 1.
2. The CPU next writes the contents of the Low byte of the specified Index Register, IXL
or IYL, to the memory location with address SPS
– 2.
SPS decrements by two.
Condition Bits Affected
None.
