ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
83
ADC A, r
ADD with Carry
Operation
A ← A+r+C
Description
The r operand is any of the 8-bit CPU registers A, B, C, D, E, H, or L. The r operand and
the Carry Flag (C) are added to the contents of the accumulator, A. The result is stored in
the accumulator.
Condition Bits Affected
Attributes
jj identifies the A, B, C, D, E, H, or L register and is assembled into one of the opcodes in
Table 38.
S Set if result is negative; reset otherwise.
Z Set if result is 0; reset otherwise.
H Set if carry from bit 3; reset otherwise.
P/V Set if overflow; reset otherwise.
N Reset.
C Set if carry from bit 7; reset otherwise.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
ADC A,r X1jj
