Zipro Dash User Manual

22
EN
PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
1
Main frame
1
33
Adjustable U washer
2
2
Front base
1
34
Nylon nut M6
2
3
Rear base
1
35
Roll wheel insert
4
4L/R
Pedal base left/right
1/1
36
Bearing
4
5
Rear base levelling end cap
2
37
Seat roller wheel
2
6
Front base pad
2
38
Nylon nut M8
6
7
Control panel column
1
39
Roller wheel
2
8
Rear support mounting plate
1
40
Nylon nut M8
2
9
Saddle bracket
2
41L/R
Left/right pedal
1/1
10
U plate
2
42
Hexagonal bolt M12x160
4
11
Cross-head screw ST4.2x18
14
43
Cross-head screw M5x15
12
12
Bracket
1
44
Internal hexagonal bolt M8x20
2
13
Handle belt
1
45
Flat washer D8x1.5
2
14
Cross-head screw ST4.2x16
4
46
Nylon nut M5
12
15L/R
Rear support cover
1/1
47
Pedal strap
2
16L/R
Main frame cover
1/1
48
Hexagonal screw M8x55
2
17
Flat washer D8x1.5
19
49
Flat washer D8x1.5
2
18
Spring washer D8
8
50
Stop pin
1
19
Hexagonal screw M8x20
10
51
Heart rate measurement cable
1
20
Separator
1
52
Connecting cable
1
21
Rubber stopper
1
53
Sensor cable
2
22
Slider track
1
54
Foam grip
2
23
Slotted screw M5x15
3
55
Bolt M8x74
1
24
Positioning column
1
56
Rubber buffer
2
25
Slider track insulation strip
2
57
Sleeve
2
26
Reinforcing column
1
58
Control panel handle
1
27
Flat washer D10Ф20x2
2
59
Slotted screw
4
28
External hexagonal bolt M10x112
1
60
Mobile device holder bracket
1
29
Nylon nut M10
1
61
Computer
1
30
Seat
1
62
Hole plug 1
2
31
External hexagonal bolt M8x125
3
63
Hole plug 2
2
32
Adjustable chain screw
2
