LB330 Parking Barrier User Manual
P a g e | 12 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Installation of the Base and the Casing
1. Remove the four screws from the casing and the base as shown in the illustration.
2. Make sure the wire slot in the centre of the base is pre-opened.
3. The base has a downward opening. Fix the location with the expansion screw M10 x 120
after identifying it.
4. Place the casing on the base and install and tighten the four screws.
The barrier's base is shown in the figure below:
