12. IR anti-pinch setting
When the gate closes, if the infrared sensors is triggered, the swing arm stops moving.
13. Version
V2.1.2
3.3 Wiring diagram and function
Check circuit according to the following wiring diagram:
Functions of terminals at each zone:
Power input 24V: The voltage is changed by a transformer to 24V and supplied to the control panel.
Firefighting port: During emergencies ensuring users fast unencumbered exit to safety.
Right open (DOWN button), left open (UP button): Controls the barrier to open to left or right
side.
Access control power supply: Supplies power for the access board.
RS485 communication port: Receiving external signals.
Electromagnetic clutch: It is connected to the electromagnet inside the core component to
prevent collision and pinch.
Connecting cable of the motor: It is connected to the motor and supplies power to the motor.
LED light: Connect to the light belt on the top of the device.
IR Sensor: It is connected to the infrared sensor to achieve anti-pinch function.
Encoder: It is connected to the encoder to determine the position of the barrier.
