ZKTeco SpeedFace-V5L Quick Start Guide

12
Once the ZKBioAccess IVS software is installed, the users could enroll their face via a
browser application on their own mobile phone.
1.
Click [Personnel] > [Parameters], input ‘’http://Server address: Port’’ in the QR
Code UGL bar. The software will automatically generate a QR code. Scan the QR
code or login onto ‘’http://Server address: Port/app/v1/adreg’’ by the mobile phone
to register users.
The users will be displayed in [Personnel] > [Temporary Personnel], click
[Review].
2.
Register on the Phone

ZKTeco SpeedFace-V5L Specifications

General

Face capacity	6000
Housing color	Black, Grey
Event capacity	200000
Built-in processor	Yes
Face recognition duration	1 s
Operating temperature (T-T)	-10 - 45 °C
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
Operating relative humidity (H-H)	10 - 90 %
Input current	3 A
Input voltage	12 V
Ethernet LAN (RJ-45) ports	1
Screen shape	Flat
Display diagonal	5 \
Display technology	TFT
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Type	Face recognition terminal

Weight and Dimensions

Depth (with stand)	22.5 mm
Width (with stand)	91.9 mm
Height (with stand)	220 mm
