TS1000ProSeriesTripodTurnstileUserManual
Page|
11
Copyright©2020ZKTECOCO.,LTD.Allrightsreserved.
3.Installtheturnstileonthemountingplateandtightenthescrews.Applyscrewsecuringgluebefore
usingandputtinggasketsonthescrewstoadjustthedirectionoftheturnstile.Ifthetripodturnstileis
notlevelled,youcanplacegasketstoadjust,asshowninFigure3-5.
InstallationlevelnessInstallationlevelness
Figure3-5
4CableDiagram
DIPK1SwitchConfiguration
Figure4-2
Pin
1
2
3
4
5
6
7
8
FunctionSetting
OpeningDuration
DirectionIndicator
ContinuePassingFunction
Alarm
Default
1
1
1
0
1
0
0
0
4.1.1SettingtheTurnstileOpeningDuration
Openingdurationreferstotheperiodoftimefromopeningtoclosingoncetheturnstilereceivesan
openingsignal.IntheDIPswitch,number1,2,and3areusedfordurationsettings.Itcanbesetto
differentvaluesfrom5sto60saccordingtothefollowingchart.
