TS1000ProSeriesTripodTurnstileUserManual
Page|
6
Copyright©2020ZKTECOCO.,LTD.Allrightsreserved.
TS1000Pro:TripodTurnstile.
TS1011Pro:
TripodTurnstilewithControllerandRFIDReader.
TS1022Pro:
TripodTurnstilewithControllerandFingerprintReaderwithRFIDfunction.
Pleasereadthisdocumentcarefullybeforeinstallationandusingthedevice.
1TechnicalSpecifications
InputVoltage
AC100~120V/200~240V,
50Hz/60Hz
Max.ToleranceofArms
Center:80kg
End:40kg
RatedPower
60W
IngressProtectionDegree
IP54
Operating
Environment
IndoorandOutdoor
(shelter)
ArmLength(mm)
500
Operating
Temperature
-28ºC~60ºC
NetWeight
36kg
OperatingHumidity
5%~85%
GrossWeight
50kg
FlowRate
Max30passages/minute
Dimension(mm)Figure1
L=520,W=310,H=1010
InputControlSignal
Drycontact
PackageSize(mm)
L=570,W=365,H=1080
Figure1
