TS1000ProSeriesTripodTurnstileUserManual
Page|
8
Copyright©2020ZKTECOCO.,LTD.Allrightsreserved.
Power-onTestbeforeInstallation
1.Pleasemakesurethatthepowerrequirementsarestrictlymettoavoidpermanentdamagestothe
unit.Inputvoltage:AC100~120V/200~240V.
Note:Thetripodturnstilemustbeconnectedtotheground(earth).
2.Poweronandwait30sforthetripodturnstiletofinishtheself-checkprogram.
3.Liftthearmsmanually,asshowninFigure2-3B.
4.CheckwhetherthetripodturnstileandtheLEDindicatorsworkproperly.
Ifthereisanyproblem,pleasecontactthesupplier.
Figure2-3AFigure2-3B
3EquipmentInstallation
InstallationConditions
Theequipmentmustbeinstalledonconcreteground,ensuringthatexpansionboltscanbesecuredfirmly.
Youaresuggestedtoinstallanassistantframeworkorfencetoformapassageway,asshowninFigure3-1.
Thereisapowerswitchintheside
directionofthispowersupply.
Earthwiringterminal
Liftupwards
