TS1000ProSeriesTripodTurnstileUserManual
Page|
7
Copyright©2020ZKTECOCO.,LTD.Allrightsreserved.
2UnpackingandTestingtheTripodTurnstile
Unpacking
Thetoppartofthetripodisheavy;donotremovethefoamliningatthebottombeforeinstallation,as
showninFigure2-1.
Figure2-1
ArmInstallation
Inordertopreventthearmfromdamagingduringtransportation,thearmwillnotbeinitiallyinstalledto
thedevices.
Installationprocedure
Putthearmkitintotheholeofcabinet;makesurethescrewholesmatchwithmechanismcore,then
tighten3hexscrews,asshowninFigure2-2.
Figure2-2
Donotremovethefoamliningat
thebottombeforeinstallation.
