ZKTeco X8-BT User Manual

1
Method 1: Install on the wall
Method 2: Install on the 86 Box
1. Device Installation
4)
Install the device on the fixed
back cover.
5)
Fix the device on the back
cover using screws.
Tamper Alarm Button
1)
Remove the screws from
the bottom of the device.
2
) Remove the back cover of
the device.
3
) Fix the back cover on the wall.
(
Drill the wiring hole and fixing
holes according to the back cover)
1) Remove the screw
s from
the bottom of the device.
2
) Remove the back cover of
the device.
3
) Fix the back cover to 86 box on
the wall
.
4)
Install the device on the back
cover.
The back cover is fixed on
the 86
box.
5)
Fix the device on the back
cover using screws.

ZKTeco X8-BT Specifications

General

Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %
DC input voltage	12 V

Weight and Dimensions

Width	90 mm
Height	38.9 mm
