ZMC420SCAN Motion Controller
2.2.5.2 Output 3-11:
Pin
number
name Explanation
1
EGND
External power
ground
2
OUT3 Output 3, PWM3,
DIR7
3
OUT4 Output 4, PWM4,
PUL8
4
OUT5 Output 5, PWM5,
DIR8
5
OUT6 Output 6, PWM6,
PUL9
6
OUT7 Output 7, PWM7,
DIR9
7
OUT8 Output 8, PWM8,
PUL10
8
OUT9 Output 9, PWM9,
DIR10
9
OUT10 Output 10, PWM10,
PUL11
10 OUT11 Output 11, PWM11,
DIR11
The PWM output of ZMC420SCAN is controlled by the normal output
function. Only the output is ON or not can the PWM be actually output,
which can be used to control the laser energy.
The output of ZMC420SCAN 0-7 has the function of precise output, the
precise output function of each output is
Independent of each other MOVEOP_DELAY and AXIS_ZSET can be used to set
whether each MOVE_OP instruction uses precise output and precise
output delay, so as to realize laser PSO control.
2.2.6
AD, DA signal
Pin
number
name Explanation
1
AD0 0-10V analog input
port 0
