ZMC420SCAN Motion Controller
29
Pin
number
sign
al
Expl
anat
ion
1 CLOCK- Clock signal
2 SYNC- Sync signal-
3 Xchannel- Galvanometer X channel signal-
4 Ychannel- Galvanometer Y channel signal-
5 NC Keep
6 STATUS- Galvanometer status signal-
7 NC Keep
8 GND Digitally
9 CLOCK + Clock signal +
10 SYNC + Sync signal +
11 Xchannel +
Galvanometer X channel signal +
12 Ychannel +
Galvanometer Y channel signal +
13 NC Keep
14 STATUS + Galvanometer status signal +
15 GND Digitally
Local axis number 4/5 can be configured as the first galvanometer with ATYPE
= 21; local axis number 6/7 can be configured as the second galvanometer with
ATYPE = 21, and the axis number can be changed through AXIS_ADDRESS
configuration.
2.3 RTEX drive settings
The default firmware configuration of the controller is 0.5ms, and the corresponding
drive configuration is:
7.20 RTEX communication
cycle
3 0.5ms
7.21 RTEX instruction
update cycle
1 0.5ms
If the controller firmware cycle is 1ms, the corresponding configuration is:
7.20 RTEX communication
cycle
6 1ms
7.21 RTEX instruction
update cycle
1 1ms
