Zodiac G2 Instruction Manual

1
INDEX
Page
SECTION 1 – INSTALLATION.................................................................2
SECTION 2 – ZODIAC ACCESSORIES ...................................................7
SECTION 3 – CARE AND MAINTENANCE..........................................8
SECTION 4 – DIAPHRAGM REMOVAL .................................................9
SECTION 5 – DIAPHRAGM ASSEMBLY ..............................................10
SECTION 6 – POOL PULSE® .................................................................11
SECTION 7 – TROUBLESHOOTING GUIDE ......................................12
WARRANTY INFORMATION ...............................................................14
1505 G2 Manual.qxp 26/9/11 8:19 AM Page 5

Zodiac G2 Specifications

General

Pool Type	In-ground
Debris Type	Small to medium
Warranty	1 year
Power Source	Filtration System
Cleaning Coverage	Floor and walls
Pool Size	Up to 40 feet
