4.3 I Removing debris from the motor
Before starng this operaon and to avoid serious injury:
• Turn o the ltraon pump.
• Disconnect the cleaner from the Twist Lock hose assembly.
• Press the buon on the top to open the lid (see image ).
• MX6 - 630 - 8 - 8 PRO - 9 - 930 : Remove the debris inside (see image ). If necessary, gently push the motor
blades forward and backward to reveal any trapped debris and remove it. When you move the blades, make sure that
the cleaner's tracks turn freely and that they are correctly synchronised with the movement of the blades under the
cleaner.
• MX10 : Remove the debris inside. If necessary, remove the motor (see image ) to reveal any trapped debris and
remove it. Make sure that the cleaner’s tracks turn freely and that they are correctly synchronised with the movement
of the blades under the cleaner when pung the motor back.
• Remove any debris which may be caught in the sucon inlet, under the cleaner.
• Close the lid and make sure it locks.
