❷ Installaon
2.1 I Setup
Hose length necessary
: Cleaner
: Hose secons
: Pool valves
: Sucon line
: Skimmer
: Filtering pump
: Filter
Sucon line connecon example
2.2 I Hose secon assembly
2.2.1 Determine the number of secons you need
• Measure the length between the sucon line or the skimmer and the furthest away point of the pool.
• Add an extra 1 metre to the length measured.
• If total length is over 10 metres (MX
TM
6 - MX
TM
630) or 12 metres (MX
TM
8 - MX
TM
8 PRO - MX
TM
9 - MX
TM
930 - MX
TM
10),
contact your reseller to purchase any addional hose secons required for your pool.
: Connecon to the sucon line or
the skimmer
: Hose length necessary
: 1 metre secon of hose with
oat
: Connecon to the cleaner
Tip: assemble the "right" quanty of hose secons
Assembling more hose secons than the length necessary to cover the whole pool is not recommended.
Hoses that are too long may limit the cleaner's performance.
2.2.2 Twist Lock Hose secon assembly
• To easily assemble the two pipe secons using the Twist Lock system, connect them then twist unl the connectors
are in complete abutment, in one of the 3 notches providing the seal (see image
).
• The secon of Twist Lock hose with the hose oat aached will be connected to the cleaner (see image ). The Twist
Lock hose oat must be located 20-23 cm away from the cleaner (see image
).
20-23 cm
Float
