Cleaner Vacuum Modes
TheMX8PoolCleanerisdesignedtooperatewithtwovacuumoptions:
1. Small debris cleaning mode (factory setting):Forvacuumingsmallerandheavydebris,suchassand,silt
andsmallstones.Thepoolcleanerissentfromthefactoryinthismode.
2. Large debris cleaning mode:(Figure11)Forvacuuminglargedebris,suchasleaves.Itisrecommended
thatyoureturnthecleanertosmalldebrisfactorysettingafterlargedebriscleaningiscomplete(Figure12).
WARNING
To avoid serious injury, make sure that the cleaner is disconnected from the hose and the suction pump used for the cleaner is turned
off prior to starting this operation.
Inlet adaptor
Front of cleaner
Front edge
Rear edge
Cleaner with the
inlet removed
Inlet adaptor
Front of cleaner
Front edge
Rear edge
Cleaner with the
inlet removed
Convert the pool cleaner to the large
debris cleaning mode:
1. Grasptheyellowinletadapterandinserta
fingerintotheadapterhole.
2. Liftuptherearedgeoftheinletadapterand
thenpullitoutofthevacuuminlet.
Convert the cleaner back to the small
debris cleaning mode:
- Placetheyellowinletadapterinthevacuum
inletofthepoolcleaner.Pushdownonthe
yellowinletadapteruntilboththefrontandrear
edgesclickintoplace.
Figure 11
Figure 12
