ENGLISH
Owner’s Manual
|
Zodiac
®
MX8
™
Pool Cleaner
CongratulationsonthepurchaseofyournewMX8automaticpoolcleaner.Builtwithproventechnology,the
MX8isdesignedandmanufacturedforeasyinstallationandyearsofcarefreeoperation.Beforeinstallingthe
cleaner,pleasetakeafewmomentstobecomefamiliarwithitscomponentsandtoreviewtheitemslistedunder
Important Information.
Likemostmechanicaldevices,theMX8requiresperiodicadjustments,routinemaintenance,andthe
replacementofcertainhardworkingparts.BesuretohavetheMX8checkedoccasionallybyyourlocaldealeror
servicecenter.
AlwaysinsistongenuineZodiacreplacementparts.Non-Zodiacpartsarenotmadetoourspecifications.They
mayhaveanadverseeffectontheoperationofyourMX8ormayevendamageit.
MX8 Components (Figure 1)
a. CleanerBody
b. Flowkeeper™Valve
c. ValveCuff
d. Twist-Lock45DegreeElbow,Extended
f. Twist-Lock45DegreeElbow
Introduction
g. FlowRegulatorValve
h. LeaderHoseSectionwithHoseFloat
j. Twist-LockHoseSection(x11)
a
b
c
d
f
g
j
h
x 11
Figure 1
