Remove Debris from Engine
WARNING
To avoid serious injury, make sure that the cleaner is disconnected from the hose and the suction pump used for the cleaner is turned
off prior to starting this operation.
1. Pushthelatchreleasebuttononthetopofthecleaner(Figure10).
2. Rotatethetopassemblybackuntilitclicksintoanupwardposition.
3. Lookintoengineandremovedebristhatispresent.
4. Ifneeded,slowlypushenginepaddlesforwardand/orbackwardstomovestuckdebristoanaccessible
positionthenremoveit.Whenmovingtheenginepaddles,makesurethecleanertracksareallowedtomove
freelyastheywillturnastheenginepaddlesrotate.
5. Closeenginetopandensurethelatchclicksinplace.
Latch Release
Button
Figure10
