5.3 I Replacing the electrical box fuse (depending on the models)
• CAUTION! Disconnect power to the appliance!
• Remove the cover,
• Disconnect the regulator,
• Remove the regulator cover,
• Remove the protec ve fuse (T3,15AH250V).
5.4 I Wiring diagrams
CA power cable: 2L+E 10/16A 3G1
TH Regula on thermostat with digital display
M1 Circula ng pump motor
F1 3.15 A-T protec on fuse
CD Flow controller
So Pool water regula on sensor (PTC)
GN Black duct
L1 "On/off " LED
L2 "Reg" LED fl ashing when med or fi xed hea ng in progress
S1 "On/off " switch
19-20 Dry command contact "normally open"
V-J Green-yellow
Bl blue
M brown
B White
N black
Earth
