Zodiac Uranus+ - Installation; 2.1 Selecting the Location

5H0360700.D - EN - 2016-02
UAN 35-70-120-240
UAN
35 255 mm 230 mm 380 mm 3/4’’ 34 mm 140 mm 45 mm 50 mm 41 mm 298 mm
70 255 mm 230 mm 380 mm 3/4’’ 53 mm 140 mm 45 mm 50 mm 41 mm 298 mm
120 255 mm 230 mm 380 mm 3/4’’ 96 mm 140 mm 45 mm 50 mm 41 mm 298 mm
240 407 mm 350 mm 500 mm 1" 87 mm 200 mm 70 mm 60 mm 71.5 mm 357 mm
Electrical unit Spherical valve
Fixed chassis Circula ng pump
Tightening plate Drainage valve
Exchange plates An -return valve
Adapta on and sealing fl ange + Injected T with spur
20/27 male screw-in + Rate controller
Connec on tubes (with caps)
Adapta on and sealing fl ange + Injected T with spur
20/27 male screw-in + Regula on sensor + Glove
fi nger
Guide bar
Tightening levers
EN
