PRECAUTIONSBEFOREUSE
1.1IMPORTANTSAFETYINSTRUCTIONS
1.2.CONTENTOFTHEPACKAGE
Thepackagingshouldcontainthefollowingitems:
x The robot, a transport caddy, a control unit, a user manual, and a remote control unit (Vortex™4 robot
only).
Checkthattheappliancehasnotbeendamagedduringtransport(shocks,brokenparts,etc.).Ifyounoticeany
defectiveparts,pleasecontactyourretailerimmediatelyandbeforeusingthecleaner.
1.3.ASSEMBLINGTHECADDY
a) Insert the top tubes (1) and (2) into the lower part of the caddy (13). Diagram 1. The handles should be
orientedtowardsthecableholderasshownindiagram1a.
b) Fitthecableholder(3)anditscover(4)onthelowerpartofthecaddy.
Diagram2.
c) Fit2longscrews(8),intothecoverwhilemaintainingthenuts(9)inthe
cableholderandtightenthem(12).
d) Fitthescrew(7)
atthebottomofthecableholderandtightenitusing
thekey(12).Diagram2.
e) Fitthecableholder(6)anditscontrolboxholder(5),fitthelongscrews
(8),inthecontrol boxholder(5)while maintainingthenuts(9)inthe
cableholderandtightenthemwiththekey(12).
f) Placethesmallscrew(7)onthetoppartofthecableholderandtighten
itusingthekey(12).Diagram3.
x Thecontrolboxmustnotbepositionedinanarealikelytoflood.
x If the control box falls into the water it is imperative that you unplug the power supply before
retrievingit.
x In order to avoid the risk of an electric shock, never open the electronic control box. Consult a
qualifiedtechnician.
x Neverattempt torepair the powersupply cable. Contactcustomer servicesin order toreplace the
originalcable,inordertoavoidanyhazards.
x Disconnect the power supply cable before any cleaning, maintenance or servicing operations and
aftereachuse.
x Inordertoavoidaccidentsoccurring,donotplaywiththecleaneroritscable.
Diagram1
Diagram2
Diagram3
