Zodiac Vortex 3 Instructions For Installation And Use

H0360600.A2.EN Ver.05/2011 8
Place the rear wheels on the support wedges (Diagram 151). Tilt the robot, then push it backwards until it
reachesitstorageposition(152).









3.3.RECYCLINGTHEPRODUCT

Whenyour appliance has reachedthe end ofitslifespan, andif you wouldlike todispose of itor
replace it: do not throw it into your household waste and do not use your household recycling
containers either. When this symbol is mentioned on an appliance, it means that the equipment
mustnotbedisposedofcasually.Itwillbecollectedselectivelysothatitcanbereused,recycledor
recovered.Anysubstancesitmaycontainwhicharepotentiallydangeroustotheenvironmentwill
beeliminatedorneutralised.
Enquirewithyourretailerfortheconditionsthatapplytotherecyclingofyourproductandtotheorganisations
thatcanhandleitsrecycling.

REPLACEMENTOFACCESSORIES


4.1.REPLACINGTHEBRUSHES


ThecleanerisfittedwithPVCbrushes.Thereare
''wear''indicatorsonthebrushes(Diagram16).
Tomaintaincleanerperformanceatitsbestyou
need to replace the brushes as soon asone of
the wear indicators has been reached (even if
thebladewearisnoteven).
We recommend that you replace the brushes
everytwoseasons.
Toremovewornbrushes,removethetabsfromtheholesinwhichtheyarefitted(Diagram17).


Tofitnewbrushesstartbyfittingthesidewithouttabsunderthebrushholder(Diagram181).
Rollthebrusharounditsholderandslidethetabsintothefixingholes.Pullontheendofeachtab(182)sothat
itsedgepassesthroughtheslit.Cutthetabsusingscissorssothattheyareatthesamelevelastheotherblades.
Repeatthisoperationwiththesecondbrush.









4.2.REPLACINGTHETYRES


4.2.1.Removingtheoldtyres

Pullontherearsideoftheoldtyre(Diagram191)
toremovethetyrelipfromthewheel.
Removetheoldtyre(192).

Thecleanercablemustbedisconnectedfromthecontrolboxbeforeremovingthecleanerfromthepool.
Windthecleanercablearoundthehookslocatedattherearofthecadd
y
startin
g
fromthecleaner.
Diagram15
Diagram17
Diagram18
Diagram19
Diagram16
EN
