SPECIFICATIONS 740 SELECT
21-22-0335 Rev D Page 38 of 40
RESPIRATION AND RR
Table 10 indicates the Specifications associated with Respiration and RR Parameter.
Patient Populations
Adult, adolescent, child and infants
Method
Impedance Pneumography
Input Connector
Same as ECG
Sensing Lead
II
RR Resolution
1 rpm (breaths per minute)
Measurement Range
0 to 120 rpm
Measurement Accuracy
±3 rpm
Measurement Sensitivity
0.25 ohms (minimum)
Report Interval
1 second
Bandwidth
0.17 to 3.3 Hz (-3dB)
Impedance Measuring Current
40 μA @ 28 kHz square wave across Lead II
Table 10: Respiration & RR Specifications
PARAMETER ALARM LIMITS & SETTINGS
Parameter
Units
Adult
Pediatric
Neonatal
Alarms On
Default
Limit
Default
Limit
Range
Alarms
On
Default
Limit
Default
Limit
Range
Alarms
On
Default
Limit
Default
Limit
Range
HR upper
bpm
Yes
120
16 – 300
Yes
120
16 – 300
Yes
180
16 – 300
HR lower
bpm
Yes
50
15 - 299
Yes
50
15 - 299
Yes
100
15 - 299
RR upper
rpm
Yes
20
6 - 150
Yes
45
6 - 150
NA
NA
NA
RR lower
rpm
Yes
5
5 - 149
Yes
10
5 - 149
NA
NA
NA
Note: Lower Alarm Limit cannot be set above the associated Upper Alarm Limit.
Note: Upper Alarm Limit cannot be set lower than the associated Lower Alarm Limit.
Table 11: HR & RR Parameter Alarm Limit Ranges
