Zoeller 503 - Page 5

5
SK2720
SUCTION
DISCHARGE
3/4 NPT
WATER SUPPLY
1 1/2
SLIP FIT
HOSE CLAMPS FOR
ATTACHING TO PRIMARY
PUMP DISCHARGE PIPE
ON LEVEL
PRIMARY PUMP
FLOAT
ON/OFF
PUMP
SUBMERSIBLE
CHECK VALVES
ABOVE SUCTION SCREEN
OFF LEVEL MUST BE
COUPLINGS
PLUG
3-PRONG
AND ABOVE PRIMARY
PUMP ON LEVEL
BY TESTING. SEE INSTRUCTIONS.
ON LEVEL TO BE DETERMINED
INCOMING WATER
SUPPLY LINE
6" MIN.
BACK FLOW PREVENTER
AND FILTER
(SUPPLIED BY OTHERS)
(SUPPLIED BY OTHERS)
ALARM MAY BE SET TO SOUND PRIOR TO BACKUP PUMP TURNING ON.
THIS WILL WARN OF MAIN PUMP FAILURE.
IF DESIRED, THE ALARM CAN BE SET TO
SOUND WHEN BACKUP PUMP ACTIVATES.
THIS WILL WARN THAT BACKUP PUMP IS
ON OR HAS FAILED.
(OPTIONAL ALARM)
INSTALL DEDICATED SHUT-OFF
VALVE WITHIN 6FT. (1.8M)
OF HOMEGUARD MAX.
P/N 10-2613
"A-PAK" ALARM SYSTEM
Note: Replace battery every 12 months
INDOOR ALARM SYSTEM 120VAC
TEST
SILENCE
R
WARNING:
ELECTRICAL SHOCK
HAZARD
FAILURE TO DISCONNECT ALL
POWER BEFORE SERVICING
COULD RESULT IN INJURY OR DEATH.
LR54245
LISTED
288X
POWER ON
ALARM
10-1494
R
LOUISVILLE, KY
R
R
PIPING ASSEMBLY
SK2721
TYPICAL INSTALLATION WITH SUBMERSIBLE PUMP
AND SEPARATE DISCHARGE PIPE
PUMP DETAILS
