Typical Outdoor Grinder Pumping System Installation
All installations must comply with all applicable electrical and plumbing codes, including but not limited
to the National Electrical Code, local, regional and/or state plumbing codes, etc.
FIGURE 6.
SK2864
24" MIN. [610mm]
WATERTIGHT
HIGH LEVEL
1 1/4" FEMALE NPT
1 1/4" [32mm] GALVANIZED
DISCHARGE PIPE
FIBERGLASS
4" [102mm] RUBBER INLET PIPE SEAL
FIBERGLASS
1 1/4" NPT BRASS
DISCONNECT FITTING
1 1/2" [38mm] SQ. GUIDE RAIL
304 STAINLESS STEEL 16 GA.
PUMP CONTROL
"ON" FLOAT
"OFF" FLOAT
PUMP CONTROL
3/8" X 1' [10mm X 305mm]
1/8" [3mm] 302 STAINLESS
NEMA 4X J-BOX
ANTI-FLOTATION FLANGE
ALARM FLOAT
SOLID
STAINLESS STEEL FLOAT HOOK
STEEL LIFTING CABLE
416 STAINLESS
1 1/4" [32mm] PVC SCH 40
PIPE AND FITTINGS
1 1/4" [32mm] PVC SLIP X SLIP
BALL VALVE
1 1/4" [32mm]
DISCHARGE FITTING
CAST IRON CHECK VALVE
COVER
(FIELD INSTALLED)
(FIELD INSTALLED)
CONTROL PANEL
FIBERGLASS BASIN
TO CONTROL PANEL
COUPLING
28" [711mm] MIN. OR PER STATE
AND LOCAL CODES
STEEL PULL ROD
60" [1524mm]
OTHER BASIN SIZES
ARE READILY AVAILABLE.
*
*
EPOXY SEALER
APPLIES TO INSIDE AND OUTSIDE INSTALLATIONS
CONDUIT
1/4" TO 1/2" [6mm TO 13mm]
WIRES OR PUMP CABLES
1 [25mm]
UL LISTED
SK2863
