ZOJE 1900D - X;Y Motor and Origin Sensor Status Check

18
The display content for each inputted No.
Input
No.
Pattern
N0. LED
X Scale
LED
Y Scale
LED
Speed
LED
Counter
LED
Winding
LED
Presser
-lowering
LED
Solenoid
LED
1 / /
2 / /
3
/ / / / / / / /
4
Pedal
Level 0
Pedal
Level 1
Pedal
Level 2
/ / / / /
5
Presser
motor
origin
sensor
Y motor
origin
sensor
X motor
origin
sensor
Thread-c
atching
origin
sensor
Thread-tr
imming
sensor
Thread-c
atching
sensor
/
/
6 Main-shaft angle display
7
Main-sha
ft motor
Z phase
/ / / / / / /
8 / / / / /
Head tilt
switch
/ /
2.4.2 CP-2（Check X/Y Motor/Origin Sensor）
Display the statuses of X/Y origin sensor, operation of searching origin and step operation of
X/Y motor.
