Table 33. L2TP/PPTP Menu Option
Option Description
PPP Address Range
(Start/End)
Configure the dedicated IP address pool for L2TP/PPTP. The
LAN IP subnet at one end of the VPN tunnel must be different
from the LAN
IP subnet at the other end of the VPN tunnel. For example, if
one side’s LAN subnet is 192.168.0.x, then the other side
should be 192.168.1.x (where the subnet mask in this
example is 255.255.255.0).
Select Enable to enable MPPE (Microsoft Point-to-Point
Encryption). MPPE is used to enhance the confidentiality of
PPP-encapsulated packets. It uses the RSA RC4 encryption
algorithm.
PPP Security (MPPE
Encryption)
Enter the user name for the L2TP or PPTP tunneling.
Username
Enter the password for the L2TP or PPTP tunneling.
Password
Re-enter to confirm the password.
Confirm Password
Show the existing user list.
User List
L2TP Server
(Preshared Phrase)
Enter a key (Pre-Shared key) for authentication. This key is
used by IPSec to validate the computer as a trusted machine.
121
