Zoom B3 User Manual

33
NEXT
Effect Types and Parameters
Effect Types and Parameters
001 OptComp This compressor is in the style of an APHEX Punch Factory.
Knob1 Knob2 Knob3
Page01
Drive 0–100 P Tone 0–100 Level 0–150
Adjusts the depth of the compression. Adjusts the tone. Adjusts the output level.
002 D Comp This compressor in the style of the MXR Dyna Comp.
Knob1 Knob2 Knob3
Page01
Sense 0–10 Tone 0–10 Level 0–150 P
Adjusts the compressor sensitivity. Adjusts the tone. Adjusts the output level.
Page02
ATTCK Slow, Fast
Sets compressor attack speed to
Fast or Slow.
003 M Comp This compressor provides a more natural sound.
Knob1 Knob2 Knob3
Page01
THRSH 0–50 P Ratio 1–10 Level 0–150
Sets the level that activates the
compressor.
Adjusts the compression ratio. Adjusts the output level.
Page02
ATTCK 1–10
Adjusts the compressor attack rate.
004 DualComp This is a compressor which allows separate settings for the low frequency and high frequency range.
Knob1 Knob2 Knob3
Page01
Hi 0–50 Lo 0–50 Freq 300Hz– 1.5kHz P
Adjusts the compression depth in
the high frequency range.
Adjusts the compression depth in
the low frequency range.
Adjusts the crossover point between the
high frequency and low frequency range.
Page02
Level 0–150 Tone 0–10
Adjusts the output level.
Adjusts the tonal quality of the sound.
005 160 Comp This compressor is in the style of the dbx 160A.
Knob1 Knob2 Knob3
Page01
THRSH -60–0 Ratio 1.0–10.0 Gain 0–20
Adjusts the threshold that determines
when the effect is activated.
Adjusts the compression ratio. Adjusts the gain after compression.
Page02
Knee Hard, Soft Level 0–150 P
Sets the type of knee. Adjusts the output level.
Effect Types and Parameters
088 DynaDelay
This dynamic delay adjusts the volume of the effect sound
according to the input signal level.
FS InputMute
Knob1 Knob2 Knob3
Page01
Time 1–2000
Sense -10–-1, 1–10 Mix 0–100 P
Sets the delay time. Adjusts the effect sensitivity.
Adjusts the amount of effected sound
that is mixed with the original sound.
Page02
F.B 0–100 Level 0–150
Adjusts the feedback amount. Adjusts the output level.
Effectnumber
Effecttype Effectexplanation Footswitch function
Parameter Parameter range
Effectscreen Pedal control possible icon Tempo synchronization possible icon
Parameter explanation

Zoom B3 Specifications

General

Simultaneous Effects	3
Display	LCD
Tuner	Yes
Power	9V DC adapter
USB	Yes
Weight	1.2 kg
MIDI I/O	No
Power Consumption	500 mA
Sampling Frequency	44.1 kHz
A/D Conversion	24-bit, 128x oversampling
D/A Conversion	24-bit, 128x oversampling
Amp Models	Yes
Looper	40 seconds
Drum Machine	Yes
Inputs	1 x 1/4" instrument
Power Source	9V DC adapter
Presets	100
Patches	100 user patches
