Continued overleaf
To connect this unit to a computer running Windows 7 (or
Windows Vista, XP) and to enable audio input/output, proceed
as follows. The installation description uses Windows 7 as an
example.
Download the latest ASIO driver from the web site of
ZOOM Corporation (http://www.zoom.co.jp) and install
the driver.
The ASIO driver software is required to enable use of Sequel LE for
audio input and output with a computer. Refer to the read_me file
included in the download package for instructions on how to install
the driver correctly.
NOTE
If the system software is an older version, the product may not be
recognized properly by the computer. It is therefore recommended to
always keep the system software updated to the latest version. The
system software can be downloaded from our web site.
Insert the supplied "Sequel LE" CD-ROM into the CD
drive of the computer, and perform the installation
steps.
Insert the CD-ROM. When the contents of the CD-ROM are shown,
double-click "Sequel LE2 for Windows" and then select "Setup.exe".
When the language selection screen appears, choose the language to
use.
After making the selection, follow the instructions on the screen.
HINT
If nothing happens when you insert the CD-ROM, open the Start menu
and select "Computer" ("My Computer" in Windows XP). Then
double-click the "Sequel LE 2 for windows" CD-ROM icon to display
the contents of the CD-ROM, and double-click the executable file
"Setup" ("Setup.exe").
NOTE
During the installation of Sequel LE, a screen asking about installation
of activation (software license authentication) management software
appears. Install this software, because it is required for registering
Sequel LE.
Connect this unit to the computer using a USB cable.
NOTE
• If you monitor the audio signal during recording via the audio output
of the computer, there will be an audible delay. Be sure to use the
[OUTPUT] jack of this unit to monitor the signal.
• When this unit is operated on USB bus power via the USB cable,
insufficient power may result in unstable operation or error
indications appearing on the computer screen or unit display.
In such a case, power the device from an AC adapter.
• Use a high-quality USB cable and keep the connection as short as
possible. If USB bus power is supplied to this unit via a USB cable
that is more than 3 meters in length, the low voltage warning
indication may appear.
HINT
• No special steps are necessary for canceling the USB connection.
Simply disconnect the USB cable from the computer.
• When you connect this unit for the first time to a computer running
Windows 7, a message saying "New Hardware Found" will appear.
Before proceeding, wait a while until this message disappears.
Bring up the "Sound" window from the Control Panel
and make the input device setting for the computer.
To bring up the "Sound" window, select "Control Panel" from the
Start menu and click "Hardware and Sound", then click "Sound".
In the "Sound" window, verify that "ZOOM G Series Audio" is listed
under the Play and Record devices and that the device is checked. (To
switch between Play and Record, click the tabs at the top of the
window.)
If the device is not checked, right-click on the icon for the device and
click "Set as Default Device" so that a check mark appears.
Launch Sequel LE and select "ZOOM G Series ASIO"
as the ASIO driver.
To start Sequel LE, double-click the Sequel LE shortcut icon that was
created on the desktop.
After Sequel LE starts, click the button in the bottom left corner of the
Multi Zone area of the Sequel window to open the settings page. Click
the Audio Connection item and select "ZOOM G series ASIO" from
the pop-up menu.
When you change the ASIO driver, a confirmation window will
appear. Click the "Switch" button.
Next, click the "Setup..." button to open a window where you can set
the latency of the ASIO driver. Set the latency as low as possible
without causing the sound to drop out during recording and playback.
[INPUT] jack
Computer
Guitar or other instrument
C adapter
Batteries
or
USB cable
This unit
[OUTPUT] jack
Audio system or other
hi-fi playback equipment
Multi Zone
Arrange Zone
Pilot Zone
USB/Sequel LE Startup Guide USB/Sequel LE Startup Guide
This USB/Sequel LE Startup Guide explains how to install Sequel LE on a computer, make connections and settings for this unit, and perform recording.
To connect this unit to a computer running MacOS X and enable
audio input/output, proceed as follows. The installation
description uses Mac OS X v10.6 as an example.
Insert the supplied "Sequel LE" CD-ROM into the CD
drive of the Macintosh.
The contents of the CD-ROM appear automatically. If nothing
happens when you insert the CD-ROM, double-click the "Sequel LE2
for Mac OS X" icon shown on the desktop.
Install Sequel LE on the Macintosh.
When the contents of the CD-ROM are shown, double-click "Sequel
LE 2.mpkg" to install the software.
Connect this unit to the computer using a USB cable.
NOTE
• If you monitor the audio signal during recording via the audio output
of the computer, there will be an audible delay. Be sure to use the
[OUTPUT] jack of this unit to monitor the signal.
• When this unit is operated on USB bus power via the USB cable,
insufficient power may result in unstable operation or error
indications appearing on the computer screen or unit display.
In such a case, power the device from an AC adapter.
• Use a high-quality USB cable and keep the connection as short as
possible. If USB bus power is supplied to this unit via a USB cable
that is more than 3 meters in length, the low voltage warning
indication may appear.
HINT
No special steps are necessary for canceling the USB connection.
Simply disconnect the USB cable from the computer.
Open the "Applications" folder and then the "Utilities"
folder, and double-click "Audio MIDI Setup".
The Audio MIDI Setup screen appears. Click "Audio Devices" and
check whether "USB Audio CODEC" is selected as default input/
default output.
If another item is selected, select the "ZOOM G Series"
After confirming the setting, quit Audio MIDI Setup.
Launch Sequel LE and set "ZOOM G Series" as the
Audio Connection.
To launch Sequel LE, click Sequel LE icon in the Applications folder.
After Sequel LE starts, click the button in the bottom left corner of the
Multi Zone area of the Sequel window to open the settings page. Click
the Audio Connection item and select "ZOOM G series" from the pop-
up menu.
When you change the driver, a confirmation window will appear.
Click the "Switch" button.
Next, click the "Setup..." button to open a window where you can set
the latency (buffer size) of the driver. Set the latency as low as possible
without causing the sound to drop out during recording and playback.
Macintosh
C adapter
or
USB cable
[INPUT] jack
Guitar or other instrument
Batteries
This unit
[OUTPUT] jack
Audio system or other
hi-fi playback equipment
Multi Zone
Arrange Zone
Pilot Zone
Continued overleaf
Sequel LE Starting Manual G-E-1
Sequel LE installation
Windows
Connections and preparation Use Sequel LE to record
Sequel LE installation Connections and preparation Use Sequel LE to record
Sequel LE installation
MacOS X
Connections and preparation Use Sequel LE to record
