Zoom GFX-8 User Manual

Naming of Parts
4
ZOOM GFX-8
Display
Top Panel
Rear Panel
GROUP/BANK indicator
DRIVE selector
MOD (modulation) selector
DLY/REV (delay/reverb)
selector
PARM (parameter)
knobs 1 - 4
GAIN knob
PARM (parameter) SELECT
/ADJUST knob
PARM (parameter)
VALUE/ADJUST knob
GROUP/CUSTOM SET key
STORE key
EDIT/CANCEL key
TOTAL key
MIDI key
ZNR/EQ EDIT key
DRIVE key
MOD (modulation) key
DLY/REV (delay/reverb) key
BANK UP/DOWN [MANUAL]
foot switches
Foot switches 1 - 4
expression pedal
INPUT jack
AUX IN jack
EXTERNAL DIST
(distortion) SEND jack
EXTERNAL DIST (distortion)
RETURN jack
OUTPUT R jack
OUTPUT L/MONO jack
OUTPUT PHONES
jack
OUTPUT LEVEL knob
POWER switch
POWER connector
MIDI IN connector
MIDI OUT connector
Naming of Parts
* The MIDI OUT connector can also be switched internally to serve as
MIDI THRU connector (see page 35).
