Zoom GFX-8 User Manual

MIDI Implimentation Chart
43
ZOOM GFX-8
MIDI Implimentation Chart
[ GUITAR EFFECT PROCESSOR ] Date : 28.SEP.1999
Model GFX-8 MIDI Implementation Chart Version :1.00
+---------------------+--------------------+--------------------+---------------------+
| | Transmitted | Recognized | Remarks |
| Function ... | | | |
+---------------------+--------------------+--------------------+---------------------+
|Basic Default | 1-16 | 1-16 | Memorized |
|Channel Changed | 1-16 | 1-16 | |
+---------------------+--------------------+--------------------+---------------------+
| Default | 3 | 3 | |
|Mode Messages | x | x | |
| Altered | ****************** | | |
+---------------------+--------------------+--------------------+---------------------+
|Note | x | x | |
|Number | True voice | ****************** | | |
+---------------------+--------------------+--------------------+---------------------+
|Velocity Note ON | x | x | |
| Note OFF | x | x | |
+---------------------+--------------------+--------------------+---------------------+
|After Key's | x | x | |
|Touch Ch's | x | x | |
+---------------------+--------------------+--------------------+---------------------+
|Pitch Bend | x | x | |
+---------------------+--------------------+--------------------+---------------------+
| | o | o | |
| | 0,32 | 0,32 | Bank select |
|Control | | 7 | Volume |
| | 1-5,7-31 (*1) | 1-5,8-31 | RTM control |
|Change | 64-95 (*1) | 64-95 | Effect module on/off|
| | 64-95 | 64-95 | Signal mute |
| | 64-95 | 64-95 | All bypass |
| | 1-5,7-31 | | Pedal control |
| | 64-95 | | CONTROL switch |
+---------------------+--------------------+--------------------+---------------------+
|Prog | o (0-79) | o (0-127) | Internally mappable |
|Change | True # | ****************** | U0.1-u9.4,A0.1-d9.4| Total 240 programs |
+---------------------+--------------------+--------------------+---------------------+
|System Exclusive | o | o | |
+---------------------+--------------------+--------------------+---------------------+
|System | Song Pos | x | x | |
| | Song Sel | x | x | |
|Common | Tune | x | x | |
+---------------------+--------------------+--------------------+---------------------+
|System | Clock | x | x | |
|Real Time | Commands | x | x | |
+---------------------+--------------------+--------------------+---------------------+
|Aux | Local ON/OFF | x | x | |
| | All Notes OFF| x | x | |
|Mes- | Active Sense | x | x | |
|sages | Reset | x | x | |
+---------------------+--------------------+--------------------+---------------------+
|Notes |
| (*1) Transmits the patch default value when program changes. |
| |
| |
+-------------------------------------------------------------------------------------+
Mode 1 : OMNI ON, POLY Mode 2 : OMNI ON, MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO x : No
* The MIDI implementation is included on the supplied CD-ROM.

Zoom GFX-8 Specifications

General

Cabinet Simulation	Yes
USB	No
Manufacturer	Zoom
Amp Modeling	Yes
Programmability	Yes
Expression Pedal	Built-in
Inputs	1/4" Input
Category	Guitar Effects
