Zoom PodTrak P4 Quick Guide

Z2I-3975-01
ZOOM CORPORATION
4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan
www.zoom.co.jp
Main Specications
Number of input channels 4 (mono/stereo)
Number of output channels 1 (headphone × 4)
Connectors MIC XLR jacks (2: HOT)
Smartphone
connection
jack
TRRS mini jack (4 contacts, TIP: L, RING1: R, RING2: GND, SLEEVE: MIC)
USB USB Type-C (audio interface and mass storage functions)
Note: Use a USB cable that supports data transfer. USB bus power is
supported.
DC 5 V USB Type-C (for power supply)
Headphones 3.5 mm stereo mini
Phantom power +48 V
Recorder Formats WAV 44.1 kHz, 16-bit, mono/stereo
Recording
media
4 GB−32 GB SDHC-compliant cards (Class 10 or higher)
64 GB−512 GB SDXC-compliant cards (Class 10 or higher)
Audio interface 44.1 kHz, 16-bit, 2-in/2-out
Power 2 AA batteries (alkaline, NiMH or lithium)
• We recommend usingNiMH batteries with the
P4
.
AC adapter (ZOOM AD-17): DC 5 V/1 A (USB bus power is supported.)
Estimated continuous
operation time using
batteries
Recording 44.1 kHz/16-bit/4ch audio to SD card (when 48 V is OFF and
headphone impedance is 63 Ω)
Alkaline batteries: about 4 hours
NiMH batteries (1900 mAh): about 4.5 hours
Lithium batteries: about 9 hours
• The above values are approximate.
• Continuous battery operation times were determined using in-house testing
methods. They will vary greatly according to use conditions.
External dimensions 112 mm (W) × 155 mm (D) × 47 mm (H)
Weight (unit only) 290 g

Zoom PodTrak P4 Specifications

Audio Specifications

number of input channels	4 (mono/stereo)
number of output channels	1 (headphone × 4)
phantom power	+48 V

Ports & Interfaces

connectors	MIC XLR jacks (2: HOT)
smartphone connection jack	TRRS mini jack (4 contacts, TIP: L, RING1: R, RING2: GND, SLEEVE: MIC)
USB	USB Type-C

Power

dc power supply	5 V USB Type-C
battery type	2 AA batteries (alkaline, NiMH or lithium)
ac adapter	DC 5 V/1 A

Battery Life

alkaline batteries operation time	about 4 hours
nimh batteries operation time	about 4.5 hours
lithium batteries operation time	about 9 hours

Weight and Dimensions

external dimensions	112 mm (W) × 155 mm (D) × 47 mm (H)
weight	290 g
