20
left pane in the Zoom Configuration Manager. (If you forgot
how to log in to the Zoom Configuration Manager, see page
10).
Advanced Setup Options
Use the links on the left pane in the Zoom Configuration
Manager under Advanced Setup Options to perform advanced
configuration tasks.
The following table lists each option under Advanced Setup and
gives a brief description of the settings you can specify.
Open page
from…
This button… Opens a page that lets you…
Advanced
Setup
WAN
Specify how your Wide Area Network ADSL setup
is configured.
Advanced
Setup
LAN
Configure LAN IP Address, LAN DHCP Server
Pool, Fixed DHCP Mapping, set up a second LAN
IP Address, and IGMP Snooping.
Advanced
Setup
NAT
Configure Virtual Servers (Port Forwarding), Port
Triggering, and a DMZ.
Advanced
Setup
Security
(IP Filtering)
Set up rules to control the forwarding of incoming
and outgoing data between your LAN and the
Internet and within your LAN. For example, you
can create IP filter rules to block attempts by
certain computers on your LAN to access certain
types of data or Internet locations. You can also
block or allow incoming access to computers on
your LAN. This page displays the current filters
and lets you edit and add filters.
Advanced
Setup
Parental
Control
Allows for URL filters to be set up.
Advanced
Setup
Quality of
Service
(Queue
Management
Configuration)
Allows different priorities to be assigned to
different applications, users, data, or guarantee a
certain level of performance to data (for upstream
only, not for downstream).
If Enable QoS checkbox is selected, choose a
default DSCP mark to automatically mark
incoming traffic without reference to a particular
classifier.
