Chapter 2: Advanced Setup Options 27
2
22
2
Return to the
Advanced Setup
page and click the
DMZ
button.
3
33
3
Select
Enable
from the
DMZ
dropdown list, and enter the
static IP address 10.0.0.16 in the
DMZ Host IP
field. Then
click
Save Changes
and
Write Settings to Flash and
Reboot
.
IMPORTANT:
Outside users who want to access the X5’s DMZ
need to use the X5’s
WAN IP address
(supplied
by your ISP), not the LAN IP address. If you
don’t know the WAN IP address, you can find it
by clicking the
System Status
icon at the top of
the X5’s main interface page and scrolling down
to the WAN Status section.
