Zotac G41 series User Manual

6
G41 series motherboard
Motherboard Layout
Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
Figure 1. Board Layout
1. 24-pin ATX Power Connector
2. IDE Connector
3. Front Panel Header
4. Speaker Header
5. Clear CMOS Jumper
6. South Bridge
7. Serial-ATA (SATA) Connectors (Optional)
8. USB Headers
9. COM Header (Optional)
10. PCI Slot
11. PCIE x1 Slot (Optional)
12. PCI Express x16 Slot
13. Front Audio Header
14. SPDIF-Out Header
15. Backpanel Connectors
16. 4-pin ATX_12V Power Connector
17. System Fan Connector(Optional)
18. CPU Fan Connector
19. DVI-PCIEX16 Select Jumper
20. CPU Socket
21. North Bridge
22. DDRIII DIMM Sockets
LOTES
R E O EVM
120
240
121
120
240
121
1.5 V 1.5 V
North Bridge
South Bridge
FP S1_
PW2
SYSFAN1
PW1
CN6
CN9
FP1
SPK1
FP_U2
FP_U1
CN1
JP1
SATA1
USB
PCI1
PCIE1
DDRIII1
KB1
DDRIII2
CPUFAN1
SD1
VGA
USB LAN_
SATA2
SATA3
SATA4
PCIE2
JP2
12
2
3
4
567
8
9
10
11
13
14
15
16
17
18
20
21 22
19
