Zotac ZBOX NANO

3
ZOTAC ZBOX nano
Product specications
Chipset
• Intel HM77
Product Dimensions
• 127mm x 127mm x 45mm
Onboard CPU
• Intel Core processor
Onboard graphics
• Intel HD Graphics 4000
• HDMI & DP output
Memory support
• One 204-pin DDR3-1600/1333 SO-DIMM slot
• Up to 8 GB of memory
USB ports
• Two USB 2.0 ports & four USB 3.0 ports
Storage support
• SATA 6.0 Gb/s transfer rates
• Supports one 2.5-inch SATA HDD/SSD (9.5mm max height) or dual mSATA SSD
via bundled nanoRAID adapter
• One eSATA port
Network support
• Gigabit (10/100/1000Mbps) LAN
• IEEE 802.3 compatible
WiFi/BT support
• 802.11b/g/n
• High speed wireless connection up to 300 Mbps
• Bluetooth v4.0
Audio
• 2-channel high-denition audio
• Jack-sensing compatible
• Optical SPDIF
Operating System support
• Windows 7 & Windows 8
• 32-bit and 64-bit support
IR receiver
• Support carrier frequencies 36k Hz
• Compatible with ZOTAC Media Remote
