Chapter4ServiceConguration
CommandFunction
zte(cfg)#setvlanvoice-vlanport<1-18>oui-id<1-32>mac-addr
<HH.HH.HH.HH.HH.HH>mac-mask<HH.HH.HH.HH.HH.HH>
AddsanOUItoaport.
zte(cfg)#setvlanvoice-vlan<1-4094>qos-profile<0-127>modify
{up|dscp|all}
Setstomodifyeitherupordscpor
both.
zte(cfg)#setvlanvoice-vlan<1-4094>qos-profiledisable
Disablestheassociationbetweena
QoSproleandavoiceVLAN.
zte(cfg)#clearvlanvoice-vlanport<1-18>
ClearsallvoiceVLANinformation
conguredonaport.
zte(cfg)#clearvlanvoice-vlanport<1-18>oui-idClearsallOUIsconguredonaport.
zte(cfg)#clearvlanvoice-vlanport<1-18>oui-id<1-32>
ClearsaspecicOUIconguredona
port.
showvlanvoice-vlan(allcongurationmodes)
Displaysvoicecongurationonall
ports.
showvlanvoice-vlanport<1-18>(allcongurationmodes)Displaysvoicecongurationonaport.
showvlanvoice-vlandefault-oui(allcongurationmodes)DisplaysthedefaultOUIofadevice.
showvlanvoice-vlanuser-tableport<1-18>(allcongurationmodes)Displaystheusertableonaport.
showvlanvoice-vlan<vlanlist>qos(allcongurationmodes)DisplaysvoiceVLANQoSconguration.
VoiceVLANCongurationInstance
lCongurationDescription
AsshowninFigure4-55,thetwoIPPhonesareinVLAN10andVLAN20,
respectively.ThevoiceVLANisVLAN100.
Figure4-55VoiceVLANCongurationInstance
lCongurationProcedure
zte(cfg)#setvlan10,20,100addport1-3tag
zte(cfg)#setvlan10,20,100enable
zte(cfg)#setvlanvoice-vlanport1oui-id1mac-addr00.00.01.00.00.01
mac-maskFF.FF.FF.FF.FF.FF
4-137
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2952E Specifications

General

Model	ZXR10 2952E
Category	Switch
Jumbo Frame	9K
Weight	4.5 kg
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 mm x 44 mm x 300 mm
Power Supply	AC 100-240V, 50/60Hz
VLAN	4K VLAN
Operating Temperature	0°C to 45°C
