LCD KVM Console User Manual

Parts

Front View

According to the size of the LCD screen is divided into two styles, as shown below, the components of the

description please see the figure after the serial number table describes the details.

Part

Function Description

Upper handle

Pull the handle, slide the LCD module out and push it in

Lock

Used to lock the LCD module, pull out the module must first

unlock, push into the automatic locking

LCD screen cover

Can be opened or closed with the handle, opening and closing
