Specification
VGA Series LCD KVM Switch Specification
Type
1 Port
4 Port
8 Port
16 Port
Model
AS-7100ULS
AS-7104ULS
AS-7108ULS
AS-7116ULS
Computer
Connection
Direct Connects
1
4
8
16
Maximum Connects
1
64
128
256
CPU Port Selection
/
OSD Menu, Front panel buttons, Hot Key, IP
Remote Control (Optional)
Connectors
Console Connector
DB 37PIN
PC
Connector
Monitor,
Keyboard/Mo
use Switch
Module
1 x VGA DB15,
USB/PS.2
4 x VGA
DB15, Female
Blue
8 x VGA
DB15,
Female Blue
16 x VGA
DB15,
Female Blue
Power
1 x DC Jack
Network Port
/
1 x RJ45
Switch
Connection Port Selection
/
KVM Operation Panel Digital keys
KVM Reset
KVM Operation Panel Function Keys
IP Module Reset
/
1 x semi-embedded key
IP Module Default
/
1 x semi-embedded key
LED’s
Selected
/
Nixie Tube Display
Online
/
4 x Red
8 x Red
16 x Red
IP Network
/
1 x Green, 1 x Orange
Analog
Mode
Keyboard/Mouse
USB, PS/2
Resolution (Max)
1920 x 1200 @ 60HZ Local & Remote
Scan time interval
3, 5, 10, 15, 20, 30, 40, 60s (3s by default)
Operating
Environment
Operating temperature
-10-50˚C
Storage temperature
-20-60˚C
Humidity
0-80%RH, No Condensation
Physical
Properties
Housing
Plastic
Metal
Dimension
50*77*24.5mm
148.4*445*45mm
Weight
0.18kg
2.7kg
3.32kg
4.96kg
