CAT5 Series LCD KVM Switch Specification
Type
4 Port
8 Port
16 Port
Model
AS-7104TLS
AS-7108TLS
AS-7116TLS
Computer
Connection
Direct Connects
4
8
16
Maximum Connects
64
128
256
CPU Port Selection
OSD Menu, Front panel buttons, Hot Key, IP
Remote Control (Optional)
Connectors
Console Connector
DB 37PIN
PC
Connector
Monitor,
Keyboard/Mouse
Switch Module
4 x VGA DB15
Female Blue, 4 x
USB
OR 4 x PS/2
8 x VGA
DB15 Female
Blue, 8 x USB
OR 8 x PS/2
16 x VGA
DB15 Female
Blue, 16 x
USB
OR 16 x PS/2
Switch Module
Port
4 x RJ45
8 x RJ45
16 x RJ45
Power
1 x DC Jack
Network Port
1 x RJ45
Switch
Connection Port Selection
KVM Operation Panel Digital keys
KVM Reset
KVM Operation Panel Function Keys
IP Module Reset
1 x semi-embedded key
IP Module Default
1 x semi-embedded key
LED’s
Selected
Nixie Tube LED Display
Online
4 x Red
8 x Red
16 x Red
IP Network
1 x Green, 1 x Orange
Analog Mode
Keyboard/Mouse
USB, PS/2
Resolution (Max)
1920 x 1200 @ 60HZ Local & Remote
Scan time interval
3, 5, 10, 15, 20, 30, 40, 60s (3s by default)
Operating
Environment
Operating temperature
-10-50˚C
Storage temperature
-20-60˚C
Humidity
0-80%RH, No Condensation
Physical
Properties
Housing
Metal
Dimension
148.4*445*45mm
Weight
2.25kg
2.74kg
3.80kg
