2N IP Force 9151101W - Page 55

Installation manual 2N® IP Force

55 / 118
•
•
•
•
•
•
•
Static IP Address Setting
Follow the instructions below to switch on theStatic IP addressmode
(DHCP OFF):
Press and hold the RESET button.
Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal can be
heard (approx. 15–35 s).
Wait until the red LED goes off andthe acoustic signal can be heard (approx. for another 3 s).
Release the RESET button.
The following network parameters will be set after restart:
IP address: 192.168.1.100
Network mask: 255.255.255.0
Default gateway: 192.168.1.1
•
•
Note
The delay after pressing RESET till the first light and sound signalling is set to 15–35 s depending on
the 2N IP intercom/answering unit model used.
24 s is the valid value for 2N
®
IP ForceHW version 8.

