2N IP Force 9151101W - Extending Module Connection

Installation manual 2N® IP Force

62 / 118
•
•
•
•
•
•
•
•
a) as close as possible to the device installed outside the building or on its
outer wall/roof,
b) as close as possible to the point where the wires leave the building.


OVP = overvoltage
protection
2.4 Extending Module Connection
2N
®
IP Forceallows the following extending modules to be connected:
Additional Switch
Internal RFID Card Reader 125 kHz
Internal RFID Card Reader 13.56 MHz
Internal secured RFID Card Reader 13.56 MHz
Security Relay
Wiegand Isolator
Induction Loop external
Induction Loop internal
