Installation manual 2N® IP Force

91 / 118
•
•
•
•
•
•
added to an existing installation. Thanksto its compact dimensions, the
device can be installed into a standard mounting box.

Connection:
Connect the2N
®
Security Relayto the intercom as follows:
To the intercom active output (OUT1 or OUT2if a reader module or additional switch is connected)
Connect the electric lock to the2N
®
Security Relayoutput as follows:
To the switched output.
To the passive output in series with the external power supply.
The device also supports a Departure button connected between the ‘PB’
and ‘- HeliosIP/IP intercom’terminals. Press the Departure button to activate
the output for 5 seconds.

Status signalling:
Green LED Red LED Status
blinking off Operational mode
on off Activated output
blinking blinking Programming mode – waiting for
initialisation
on blinking Error – wrong code received
Configuration:
Connect the2N
®
Security Relayto the properly set intercom switch output; refer tothe Configuration
Manual. Make sure that one LED at least on the2N
®
Security Relayis on or blinking.
Press and hold the2N
®
Security RelayReset button for 5 seconds to put the devicein the programming
mode (both the red and green LEDs are blinking).
Activate the intercom switch using the keypad, telephone, etc. The first code sent from theintercom will be
stored in the memory and considered valid. After code initialisation, the2N
®
Security Relaywill pass into
the operational mode (the green LED is blinking).
